LUMATEK DAISY CHAIN 5M CONTROL CABLE
This 5m long Control Link Cable is designed to daisy-chain your LUMATEK Controllable LED Fixtures allowing a stable and precise connection without any interference. Simply connect the M12 Self-locking male plug into the Signal Out LED structure output and the M12 Self-locking female plug into the Signal In LED structure input of the next fixture.
Wire Gauge: UL 2464 3×22AWG 80℃ 300V VW-1
TECHNICAL/TEST DATA:
– Withstand voltage between conductor and insulator is 800 VAC, 2mA, test time 60S, no breakdown or leakage current occurs
– Temperature Resistance: 80℃
– Working temperature: -20℃-105℃
– Storage temperature: -25℃-105℃
– IP65
– Comply RoHS
